Technical particularity

Working speed: 0.1mm ~ 1m / s (and drive the way)

Rating: 5 (2) A250VAC / 5A 125VAC (the default value), 1 (0.3) A250VAC / 1A125VAC

Operating Frequency: Mechanical 60 beats / min, electric 25 beats / min

Insulation resistance: ≥100mΩ (500VDC)

Contact resistance: ≤50MΩ

Withstanding voltage: contact between terminals with extremely AC1000V, 50 / 60Hz, 1min

         Between the carrying metal parts and ground, AC1500V between the terminal and uncharged metal parts, 50 / 60Hz, 1min

Anti-Vibration: 10 ~ 55Hz, 1.5mm d double amplitude

Anti-shock: Durable: 1000M / S ^ 2 (about 100G) max

         Malfunction: 300M / S ^ 2 (about 30G) max

Life: Mechanical ≥1,000,000 times

         Electrical ≥50,000 times

Electric shock protection class: Ⅱ grade

Enclosure protection class: IEC IP65

Safety Certification: UL, CUL, TUV, CE, SEMKO
